pLL7.0: mTiam1(64-437)-tgRFPt-SSPB R73Q
(Plasmid #60418)

Ordering

Item Catalog # Description Quantity Price (USD)
Plasmid 60418 Standard format: Plasmid sent in bacteria as agar stab 1 $85

This material is available to academics and nonprofits only.

Backbone

  • Vector backbone
    pLentiLox7.0
  • Vector type
    Mammalian Expression, Lentiviral, Cre/Lox

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    NEB Stable
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    mTiam1-tgRFPt-SSPB R73Q
  • Species
    M. musculus (mouse), Synthetic
  • Insert Size (bp)
    2289
  • Mutation
    mTiam 64-437 // SSPB R73Q, Y11K and A15E
  • Promoter CMV
  • Tag / Fusion Protein
    • tgRFPt

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site ApaI (not destroyed)
  • 3′ cloning site PciI (not destroyed)
  • 5′ sequencing primer none
  • 3′ sequencing primer CAGCAACCAGGATTTATACAAGG
  • (Common Sequencing Primers)

Resource Information

Terms and Licenses

Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

The SspB used in this construct contains two amino acid mutations that disrupt the natural dimerization of SspB. These mutations are Y11K and A15E (residue numbering from pdb code 1ou9). Here is the sequence around the mutated residues with the sites of mutation in parentheses: SSPKRP(K)LLR(E)YYDWLVDNS

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pLL7.0: mTiam1(64-437)-tgRFPt-SSPB R73Q was a gift from Brian Kuhlman (Addgene plasmid # 60418 ; http://n2t.net/addgene:60418 ; RRID:Addgene_60418)
  • For your References section:

    Engineering an improved light-induced dimer (iLID) for controlling the localization and activity of signaling proteins. Guntas G, Hallett RA, Zimmerman SP, Williams T, Yumerefendi H, Bear JE, Kuhlman B. Proc Natl Acad Sci U S A. 2015 Jan 6;112(1):112-7. doi: 10.1073/pnas.1417910112. Epub 2014 Dec 22. 10.1073/pnas.1417910112 PubMed 25535392
