Pvalb-2A-Flpo Flp-in replacement vector
(Plasmid #61572)

Ordering

Item Catalog # Description Quantity Price (USD)
Plasmid 61572 Standard format: Plasmid sent in bacteria as agar stab 1 $85

This material is available to academics and nonprofits only.

Backbone

  • Vector backbone
    pUC57
  • Backbone size w/o insert (bp) 2682
  • Total vector size (bp) 6248
  • Modifications to backbone
    MCS region was modified
  • Vector type
    Recombinase-mediated cassette exchange using Flp recombinase
  • Selectable markers
    Partial Hygro sequence

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    Pvalb-2A-Flpo
  • Alt name
    Flpo
  • Species
    M. musculus (mouse), S. cerevisiae (budding yeast)
  • Insert Size (bp)
    3566

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site Kpn (not destroyed)
  • 3′ cloning site Sac1 (not destroyed)
  • 5′ sequencing primer TCTTCGCTATTACGCCAGCT
  • 3′ sequencing primer AACAGCTATGACCATG
  • (Common Sequencing Primers)

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    Pvalb-2A-Flpo Flp-in replacement vector was a gift from Hongkui Zeng (Addgene plasmid # 61572 ; http://n2t.net/addgene:61572 ; RRID:Addgene_61572)
  • For your References section:

    Transgenic mice for intersectional targeting of neural sensors and effectors with high specificity and performance. Madisen L, Garner AR, Shimaoka D, Chuong AS, Klapoetke NC, Li L, van der Bourg A, Niino Y, Egolf L, Monetti C, Gu H, Mills M, Cheng A, Tasic B, Nguyen TN, Sunkin SM, Benucci A, Nagy A, Miyawaki A, Helmchen F, Empson RM, Knopfel T, Boyden ES, Reid RC, Carandini M, Zeng H. Neuron. 2015 Mar 4;85(5):942-58. doi: 10.1016/j.neuron.2015.02.022. 10.1016/j.neuron.2015.02.022 PubMed 25741722
