PurposePlasmid for recombinant expression in bacteria of SpyLigase. The Howarth lab has created two improved peptide ligation enzymes. See depositor comments below!
|Item||Catalog #||Description||Quantity||Price (USD)|
|Plasmid||51722||Standard format: Plasmid sent in bacteria as agar stab||1||$75|
This material is available to academics and nonprofits only.
Backbone manufacturerLife Technologies
- Backbone size w/o insert (bp) 6400
- Total vector size (bp) 6727
Modifications to backboneN/A
Vector typeBacterial Expression
Growth in Bacteria
Bacterial Resistance(s)Ampicillin, 100 μg/mL
Copy numberHigh Copy
Insert Size (bp)327
- Promoter T7
/ Fusion Protein
- His6 Tag (N terminal on insert)
- Cloning method Ligation Independent Cloning
- 5′ sequencing primer TAATACGACTCACTATAGGG
- 3′ sequencing primer GCTAGTTATTGCTCAGCGG (Common Sequencing Primers)
Articles Citing this Plasmid
Terms and Licenses
- Not Available to Industry
- Zeocin® is an InvivoGen trademark.
SnoopLigase is the more recent peptide-peptide ligation technology from the Howarth lab and is now preferred over SpyLigase in terms of more general reaction conditions and higher coupling yield on a range of proteins.
SpyLigase peptide-peptide ligation polymerizes affibodies to enhance magnetic cancer cell capture. Jacob O. Fierer, Gianluca Veggiani and Mark Howarth
Transform plasmid into BL21 DE3 RIPL for expression.
These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.
For your Materials & Methods section:SpyLigase was a gift from Mark Howarth (Addgene plasmid # 51722 ; http://n2t.net/addgene:51722 ; RRID:Addgene_51722)
For your References section:SpyLigase peptide-peptide ligation polymerizes affibodies to enhance magnetic cancer cell capture. Fierer JO, Veggiani G, Howarth M. Proc Natl Acad Sci U S A. 2014 Mar 17. 10.1073/pnas.1315776111 PubMed 24639550
