(Plasmid #89346)


Item Catalog # Description Quantity Price (USD)
Plasmid 89346 Standard format: Plasmid sent in bacteria as agar stab 1 $85

This material is available to academics and nonprofits only.


  • Vector backbone
  • Total vector size (bp) 11654
  • Vector type
    Mammalian Expression, Lentiviral
  • Selectable markers

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
  • Growth Strain(s)
    NEB Stable
  • Copy number
    High Copy


  • Gene/Insert name
    TCR beta gene (Jurkat allele) fused at the N terminus to the SNAP tag
  • Species
    H. sapiens (human)
  • Promoter SFFV
  • Tag / Fusion Protein
    • SNAPf tag (N terminal on insert)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site Mlu1 (not destroyed)
  • 3′ cloning site BamH1 (unknown if destroyed)
  • 5′ sequencing primer SFFV for (GCTTCCCGAGCTCTATAAAAGAGC)
  • 3′ sequencing primer IRES rev, WPRE rev
  • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
  • Zeocin® is an InvivoGen trademark.
How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    DNA-CARtcr-IRESpuro was a gift from Ron Vale (Addgene plasmid # 89346 ; ; RRID:Addgene_89346)
  • For your References section:

    A DNA-Based T Cell Receptor Reveals a Role for Receptor Clustering in Ligand Discrimination. Taylor MJ, Husain K, Gartner ZJ, Mayor S, Vale RD. Cell. 2017 Mar 23;169(1):108-119.e20. doi: 10.1016/j.cell.2017.03.006. 10.1016/j.cell.2017.03.006 PubMed 28340336
