pCMV-Myc CDC4 WT*
(Plasmid #16652)

Ordering

This material is available to academics and nonprofits only.
Item Catalog # Description Quantity Price (USD)
Plasmid 16652 Standard format: Plasmid sent in bacteria as agar stab 1 $85

Backbone

  • Vector backbone
    pCMV-Myc
  • Backbone manufacturer
    Clontech
  • Backbone size w/o insert (bp) 3800
  • Vector type
    Mammalian Expression

Growth in Bacteria

  • Bacterial Resistance(s)
    Ampicillin, 100 μg/mL
  • Growth Temperature
    37°C
  • Growth Strain(s)
    DH5alpha
  • Copy number
    High Copy

Gene/Insert

  • Gene/Insert name
    CDC4
  • Alt name
    Archipelago
  • Species
    H. sapiens (human)
  • Insert Size (bp)
    1500
  • Mutation
    *Note that this insert is only WT relative to the mutant version (www.addgene.org/16653). This is not full length CDC4. See comments and paper for specifics.
  • Entrez Gene
    FBXW7 (a.k.a. AGO, CDC4, DEDHIL, FBW6, FBW7, FBX30, FBXO30, FBXW6, SEL-10, SEL10, hAgo, hCdc4)
  • Tag / Fusion Protein
    • myc (N terminal on backbone)

Cloning Information

  • Cloning method Restriction Enzyme
  • 5′ cloning site BglII (not destroyed)
  • 3′ cloning site NotI (not destroyed)
  • 5′ sequencing primer n/a
  • 3′ sequencing primer EBV rev
  • (Common Sequencing Primers)

Resource Information

Terms and Licenses

  • Academic/Nonprofit Terms
  • Industry Terms
    • Not Available to Industry
Trademarks:
  • Zeocin® is an InvivoGen trademark.

Depositor Comments

A 1.5kb fragment of human CDC4 cDNA (nucleotides 374-1874), which encompasses the entire ORF, was cloned into pCMV-Myc.

Addgene's quality control sequence suggests there are some unexpected mutations in the gene. The effect these mutations have on function is unknown, but this is the plasmid used in the Vogelstein article, so it should behave as reported.

How to cite this plasmid ( Back to top)

These plasmids were created by your colleagues. Please acknowledge the Principal Investigator, cite the article in which the plasmids were described, and include Addgene in the Materials and Methods of your future publications.

  • For your Materials & Methods section:

    pCMV-Myc CDC4 WT* was a gift from Bert Vogelstein (Addgene plasmid # 16652 ; http://n2t.net/addgene:16652 ; RRID:Addgene_16652)
  • For your References section:

    Inactivation of hCDC4 can cause chromosomal instability. Rajagopalan H, Jallepalli PV, Rago C, Velculescu VE, Kinzler KW, Vogelstein B, Lengauer C. Nature. 2004 Mar 4. 428(6978):77-81. 10.1038/nature02313 PubMed 14999283
